Super link side dump trailer for sale

Product Item：GT0603Z

Payload (kgs):50000

Tare weight (kgs):8800

Dimensions (mm) (Customize )

Axles:13 ton(16ton,20ton) capacity

Description

QINGDAO SHIYUN TRAILER CO.,LD ,is a professional China Trailer manufacturer with brand “girder trailer”.For transporting and unloading sand ,coal,soil,stone and other bulk cargo ,we provide different kinds of hydraulic dump trailers .According to the different function and tipping direction ,We have end dump trailer,side dump trailer ,container skeletal /flatbed dump trailer and conveyor belt type trailer.

Super link side dump trailer for sale/side tipper trailer:

Features:

1.The volume can be design from 10cbm-100cbm

2.Axles number can be 1,2,3,4 axles or superlink axles for transporting different weight cargo.

3.The hydraulic cylinders can be HYVA or other brand optional .

4.The hydraulic cylinder can be installed in the bottom of the van body or at the front and rear side of the van body.

5.Main beam can be straight beam or step deck type.

6.The thickness of the side wall and floor are according to transporting different cargoes.

7.The roof can be covered by tarpaulin.

8.Suspension can be normal leaf springs suspension ,air suspension or bogie suspension.

Parameters:

Model	GT0603Z
Size	1200025001600 (mm) ( customizable )
Axles	3* 13ton capacity (Brand optional)
Suspension	Mechanical suspension with leaf springs (Air suspension /bogie optional)
Tire	12R22.5 11.00R20 12pcs (Other size optional)
Rim	9.00-22.5 8.00-20 12pcs (Other size optional)
King pin	2’’/3.5’’ bolt type
Landing gear	28 Ton two speed
Braking system	Double air chamber ,brake valve,40L air tanks ;ABS optional
Electrical	LED light , 7 ways ,24V
Painting	Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
