3 axles Hopper Silo wheat trailer,grain semi trailer

Product Item：GT0301CTC

Payload (kgs):50000

Material:Steel/Aluminum

Side board height:1800-3000mm optional

Axles:2/3/4 pcs optional

Description

QINGDAO SHIYUN TRAILER CO.,LD ,is a professional China Trailer manufacturer with brand “girder trailer”.For different kinds of cargo transporting ,we have different kinds of trailer solutions: flatbed trailer with side bar,drop side trailer,fence trailer,dry van trailer,wing van trailer,reefer trailer,curtain side trailer,log trailer,silo trailers and livestock trailers.

Hopper silo wheat semi trailer,grain trailer:

Features:

1.The length can be from 10meters to 15meters.

2.Pay load from 30-100tons

3.Axles number can be 1,2,3 or 4 axles for transporting different weight cargo.

4.The material can be high strength Mn carbon steel or aluminum material.

5.Hopper shape for unloading the grains.

6.Pneumatic valve to control the bottom door.

7..Suspension can be normal leaf springs suspension ,air suspension or bogie suspension.

Parameters:

Model	GT0301CTC
Size (L*W)	12500*2500 (mm)
Height	3000mm~4200mm
Main beam	Heavy duty I beam.
Axles	2/3/4 * 13ton capacity (BPW,FUWA,L1 and other Brand optional)
Suspension	Mechanical suspension (Air suspension/Bogie suspension optional)
Leaf spring	10pcs
Tire	12R22.5 315/80R22.5 295/80R22.5 12pcs (Other size optional) 385/65R22.5 6pcs
Rim	9.00-22.5 12pcs (Other size optional)
King pin	2’’/3.5’’ bolt type
Landing gear	28 Ton two speed
Braking system	Double air chamber ,brake valve,32L air tanks ;ABS optional
Electrical	LED light , 7 ways ,24V
Painting	Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
