Length extendable tank transport trailer

Product Item：GTGC70T

Length extendable

oversized tank transporting

payload 30-200tons

axis steering or normal optional

Description

Oversized tank transport trailer -Length extendable tank transport trailer

Usage :Transport large-scale equipment tank body or wind tower.

Some large-scale production equipment are the focus of development in many fields, such as wind power, petrochemical, and engineering. The components of these large-scale production equipment, especially tank-type parts, have a diameter of more than 4 meters, more than 30 meters in length, more than 100 tons in weight.

This kind of trailers are professional for transporting the above cargo.

There are some mainly types of tank transporter trailers as follow:

Tank transport ultra low bed trailer ,

Width/length extendable oversized tank transport trailer

Steering axles tank transport trailer

Heavy duty lift dolly tank transport trailer with concave platform

Tank transport modular trailer

Clamped type tank transport trailer with concave platform

SPMT tank transport trailer

Length extendable tank transport trailer:

Features :

1.Length extendable tank trailer can transport different length oversized tanks.

Trailer body can be 13meters to 30meters

2.The platform height can be made very low.It can be 350mm-900mm from the ground.

3.It has normal axles type and steering axis type. Normal axles type can have 2-4 axles ,Steering axles can have more than 5 axles .

4.The payload is from 30tons to 200tons .

Parameters:

Model	GTGC70TDP
Payload	30000KG-200000KGS
Platform	With radian for different diameters tank bodies ,Length extendable
Axles	2-10 axis lines optional
Tire	Optional
Power station	Optional
Braking system	Double air chamber ,brake valve,ABS optional
Electrical	LED light , 7 ways ,24V
Painting	Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
