4 axles low bed trailer，quad low loader trailer

4 axles low bed trailer，quad low loader trailer

Product Item：GT0401TDP

Payload (kgs):70000

Tare weight (kgs):10000

Dimensions (mm):13500*3000*1000

Axles :13 ton(16ton,20ton) capacity

Description

LOW BED TRAILER -4 axles drop deck trailer

QINGDAO SHIYUN TRAILER CO.,LD ,is a professional China Trailer manufacturer with brand “girder trailer”.Low bed trailer is a kind of semi-trailer that has a super low cargo platform, the platform is also called drop-deck. Mainly specialized for transportation of crawler crane, excavator, crawler loader, bulldozer, railroad equipment, and other crawlers/tires equipment. Benefit from the low bed design, the trailer has high trafficability to go through bridge arc and tunnel, and lowers COG(center of gravity) of cargo.The trailer body has a drop-deck which is lower than the front gooseneck and the rear wheel-set, due to the drop deck design, it always comes with a gooseneck, so it is also called low bed semi-trailer.

Basic Features:

1. Suspension is mechanical spring suspension or air suspension

2. Can be designed flatbed type or concave beam type

3. Side bracket is an option for widening drop deck, removable and swinging

4. The design can be expose tires type or covered tires type

5. The ramps can be mechanical spring type or hydraulic type optional

6. Can be with twist lock for container transporting

7. Commercial trailer or military trailer optional

[GIRDER TRAILER] Features:

1. Can be together will front towing dolly for over heavy duty cargo transporting.

2. Lifting function optional :hydraulic lifting suspension be able to adjust height

3. Can make telescopic beam to realize length extension optional .

4.Higher strength steel to ensure the low platform not drop down.Arc-up design for the cargo platform deck,can be flatbed type also.

5.Drop deck minimize trailer’s platform height, increase trafficability and stability for over height cargo.

6. The cover surface of the platform can be wood to anti-skidding or diamond checked plate.

7.Gooseneck can be normal or hydraulic detachable type.Power pack with valves optional

Parameters:

Model	GT0401TDP
Size	1400030001100 (mm)
Payload	80000KG
Main beam	Heavy duty I beam.
Side beam	250mm I beam
Plate	5mm checked plate
Ladder	Mechanical spring ladder or hydraulic ladder
Axles	4 * 13ton capacity (BPW,FUWA,YORK,L1 ,Anhui and other Brand optional)
Suspension	Mechanical suspension (Air suspension optional)
Leaf spring	10pcs
Tire	12R22.5 / 11.00R20 16pcs (Other size optional)
Rim	9.00-22.5 / 8.00V-20 16pcs (Other size optional)
Kin pin	2’’/3.5’’ bolt type
Landing gear	40 Ton two speed
Braking system	Double air chamber ,brake valve,45L air tanks ;ABS optional
Electrical	LED light , 7 ways ,24V
Painting	Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting

Above data can be customized per your local regulation and requirement.
